Product Description
BUFFALO TURBINE BT-MDC2 MONSOON DIESEL DUST CONTROLLER WEIGHT 975 LBS
DESCRIPTION
MONSOON DIESEL DUST CONTROLLER Diesel Dust/Odor Controller, (KDW1003-5021BUFF 3 Cylinder / Tier 4, Liquid Cooled Kohler Engine) and Wireless remote w/ throttle and nozzle control, 12 gallon fuel capacity (includes lifting bracket and fork pockets)
- Misting System Gyratory Atomizing Nozzle
- Hose Input 3/4" Utility / Garden Hose
- Minimum Water Volume 1/3 Gallon Per Minute
- Maximum Water Volume 20 Gallons Per Minute @ 120psi
- Minimum Water Pressure 40 psi Maximum Water Pressure 120 psi
- Droplet size 50-200 Microns
- Throw Distance Horizontal Up to 125 ft. in Neutral Wind Conditions
- Throw Distance Vertical Up to 50 ft. in Neutral Wind Conditions
- Warranty 10 Year Manufacturer Warranty
- Engine Warranty 3 Year Warranty
- Input Power KDW1003 Kohler Engine Input RPM Up to 3600 RPM
- Outlet Size 12”
- Oscillation Settings up to 270°
- Length with wheels and handle removed 88”
- Overall Length with Nozzle and tow handle 136”
- Width 55”
- Max Height with nozzle in upright position 54”
- Weight 975 lbs.
- Transmitter Hand held wireless transmitter (water resistant) with push button control (manual control option available)
Key Features
- Warranty Protection: 10-year manufacturer warranty on the dust controller and 3-year warranty on the engine.
- Efficient Power Usage: Kohler engine with input RPM up to 3600 RPM for reliable operation.
- Compact and Portable: Length of 88" with wheels and handles removed; 136" overall with nozzle and tow handle.
- Optimal Water Flow: Handles water volumes between 1/3 GPM and 20 GPM for customized dust control.
Detailed Specifications
| Specification | Details |
|---|---|
| Part # | BT-MDC2 |
| Manufacturer | Buffalo Turbine |
| Category | Dust & Odor Control Equipment |
| Subcategory | Diesel |
| Industry | Construction |
| Engine | KDW1003 Kohler Diesel Engine |
| Engine RPM | Up to 3600 RPM |
| Water Input | 3/4" Utility / Garden Hose |
| Water Volume | Min: 1/3 Gallon/min, Max: 20 GPM |
| Water Pressure | Min: 40 PSI, Max: 120 PSI |
| Throw Distance | Horizontal: 125 ft, Vertical: 50 ft |
| Droplet Size | 50-200 microns |
| Oscillation | 270° |
| Transmitter | Wireless, Water-resistant, Push button control |
| Dimensions (L x W x H) | 136" x 55" x 54" (Max Height) |
| Weight | 975 lbs |
| Warranty | 10-year Manufacturer Warranty, 3-year Engine Warranty |
In Package
- Buffalo Turbine BT-MDC2 Monsoon Diesel Dust Controller
- KDW1003 Kohler diesel engine
- Handheld wireless transmitter (water-resistant)
- Lifting bracket and fork pockets for transport
- User manual for setup and operation
